2025 Nissan Pathfinder Lug Nut Torque & Bolt Specs

The 2025 Nissan Pathfinder lug nut torque is 83 ft-lbs (113 Nm), tightened with a 21mm socket on M12x1.25 studs. Torque in a star pattern in two passes (snug, then final), and re-check after the first 50–100 miles of driving. Use a calibrated torque wrench — not an impact gun — for the final pass.

Lug nut torque: 83 ft-lbs (113 Nm) · Socket size: 21mm · Thread: M12x1.25.

This page is the OEM-referenced fastener summary for the 2025 Nissan Pathfinder. Use it before any maintenance or repair job where torque values matter — brake work, wheel changes, suspension service, engine teardowns, or oil changes. Specs are pulled from manufacturer service literature, cross-checked against community data, and updated as new chassis variants become available.

Nissan lug-nut torque is 83 ft-lbs (113 Nm) for nearly every passenger model since 2000 with an M12x1.25 thread (note: tighter pitch than Toyota/Honda's M12x1.5 — the lugs do not cross-thread cleanly with neighboring makes). Socket size is 21mm. Titans and Armadas use a larger M14x1.5 thread at 133 ft-lbs.

Common fastener categories on the 2025 Nissan Pathfinder

Wheel / lug nut torque and thread spec (covered above)
Brake caliper bracket bolts (typically 80-130 ft-lbs) and slide/guide pins (18-35 ft-lbs)
Engine oil drain plug torque — rarely above 30 ft-lbs; always use a new crush washer
Transmission pan, valve cover, and intake manifold bolts (low torque, often 89-106 in-lbs)
Suspension control arm, sway bar, tie rod end and ball joint torque
Spark plug torque (typically 10-15 ft-lbs on aluminum heads — do not exceed)
Differential cover bolts (RWD/4WD only) and transfer case fasteners

Repair guidance for this model year

For 2025 late-model work: Modern vehicles increasingly use aluminum body and suspension components. Aluminum fastener torque is typically 60-70% of equivalent steel torque, and aluminum threads strip easily. Use a calibrated torque wrench and apply anti-seize on any steel fastener threading into aluminum.

Tools you will need

Metric socket set (8mm-22mm), 6-point impact-rated
Calibrated torque wrench (10-150 ft-lbs covers most automotive jobs; add a 0-250 ft-lbs wrench for truck lug nuts)
Breaker bar (24" minimum) for initial loosening
Penetrating oil (PB Blaster or Kroil) for any fastener over 5 years old
Anti-seize on stainless or dissimilar-metal threads; thread-locker (Loctite blue) on critical reassembly

Frequently asked questions

What is the lug nut torque on a 2025 Nissan Pathfinder?

The OEM-specified lug-nut torque for the 2025 Nissan Pathfinder is 83 ft-lbs (113 Nm), using a 21mm socket on M12x1.25 thread studs. Use a calibrated torque wrench in a star pattern, in two passes (50% and 100%), and re-check after 50-100 miles of driving.

What socket size do I need for the 2025 Nissan Pathfinder lug nuts?

The 2025 Nissan Pathfinder uses a 21mm socket. A 6-point impact-rated socket is recommended over a 12-point chrome socket — 12-points round off lug nuts under impact-driver use.

Are the 2025 Nissan Pathfinder fasteners metric or SAE?

Metric is the standard for this vehicle. Most fasteners on this vehicle are metric (M6, M8, M10, M12, M14). Bring a full metric set; SAE substitutes can round the head. Bolt-head markings are the fastest way to confirm grade and material at the bench.

Other Nissan Pathfinder years

Same model, different model year — fastener spec may change. Always confirm against the year for your VIN.

→ 2025 Nissan Pathfinder oil drain plug torque & size

→ 2025 Nissan Pathfinder lug nut torque: step-by-step & re-torque guide

→ 2025 Nissan Pathfinder suspension & steering torque specs (control arm, ball joint, tie rod)

All 19 2025 Nissan Pathfinder fastener specs

Per-bolt torque, wrench size, and thread spec for the 2025 Nissan Pathfinder, sourced from OEM service literature and verified against community shop data. Values pair imperial (ft-lb) and metric (Nm) where the manufacturer publishes both. 16 of the 19 fastener specs on this page are independently verified against OEM service manuals and manufacturer torque data (last reviewed June 2026).

Brakes — 2025 Nissan Pathfinder

Brake fasteners on the 2025 Nissan Pathfinder — caliper bracket, slide pins, and banjo bolt torque follow. At the front caliper, the front brake caliper bracket bolt torques to 133 ft-lbs (180 Nm). OEM-verified spec. For the front caliper, plan for the right driver; final torque is 34 ft-lbs (46 Nm) (front brake caliper guide pin bolt). Confirmed against manufacturer service literature.

Engine — 2025 Nissan Pathfinder

Engine bolt-by-bolt torque for the 2025 Nissan Pathfinder, including the long block, valve covers, and intake. For the vq35dd valve cover, plan for a 10mm tool on a M6x1.0 stud; final torque is 7 ft-lb (9 Nm) (valve cover bolt). Confirmed against manufacturer service literature. Oil drain plug tightens to 25 ft-lbs (34 Nm), takes a 14mm driver, runs on M14x1.5 threads, located at the oil pan. This figure is independently verified against OEM service data. The spark plug uses a 5/8" (16mm) drive on a M14x1.25 thread, torqued to 18 ft-lbs (25 Nm) at the cylinder head — vq35dd. OEM-verified spec. At the engine oil filter housing, the oil filter torques to Hand tight + 3/4 turn (65mm cap wrench drive). Confirmed against manufacturer service literature.

Drivetrain — 2025 Nissan Pathfinder

Drivetrain and driveline fasteners for the 2025 Nissan Pathfinder — axle, transmission, and differential plugs. Front axle hub nut tightens to 101 ft-lb (137 Nm), takes a 36mm driver, runs on M24x1.5 threads, located at the front wheel hub / cv axle. This figure is independently verified against OEM service data. The rear differential drain plug uses a 24mm drive, torqued to 47 ft-lb (64 Nm) at the rear differential housing (awd). OEM-verified spec. At the zf 9-speed transmission pan, the transmission drain plug torques to 29 ft-lb (39 Nm) (10mm Allen drive). Confirmed against manufacturer service literature.

Suspension — 2025 Nissan Pathfinder

Suspension and chassis fastener torque for the 2025 Nissan Pathfinder — strut, control arm, and sway bar values. The front strut-to-knuckle bolt uses a 19mm drive on a M12x1.25 thread, torqued to 98 ft-lbs (133 Nm) at the front strut lower pinch. At the front strut upper mount, the front strut top nut torques to 43 ft-lb (59 Nm) (22mm drive, M12x1.25 thread). Confirmed against manufacturer service literature. For the front stabilizer bar end link, plan for a 17mm tool on a M12x1.25 stud; final torque is 52 ft-lbs (71 Nm) (front sway bar link nut). Front lower control arm bolt tightens to 109 ft-lbs (148 Nm), takes a 19mm driver, runs on M14x2.0 threads, located at the front lower control arm to subframe.

Brake — 2025 Nissan Pathfinder

Brake fasteners on the 2025 Nissan Pathfinder. At the caliper bracket to knuckle, the front caliper bracket bolt torques to 107 ft-lbs (145 Nm) (22mm drive, M14x1.5 thread). Confirmed against manufacturer service literature. For the rear caliper to bracket, plan for a 14mm tool on a M10x1.25 stud; final torque is 34 ft-lb (46 Nm) (rear brake caliper bolt). This figure is independently verified against OEM service data. Rear caliper bracket bolt tightens to 65 ft-lb (88 Nm), takes a 21mm driver, runs on M14x1.5 threads, located at the rear caliper bracket to knuckle. OEM-verified spec. The brake bleeder screw uses a 8mm drive, torqued to 12 ft-lbs (16 Nm) at the caliper bleeder. Confirmed against manufacturer service literature. At the front caliper to bracket, the front brake caliper bolt torques to 34 ft-lb (46 Nm) (17mm drive, M12x1.25 thread). This figure is independently verified against OEM service data.

Wheels & Tires — 2025 Nissan Pathfinder

Wheels & Tires fasteners on the 2025 Nissan Pathfinder. For the wheel hub, plan for a 21mm tool on a M12x1.25 stud; final torque is 83 ft-lbs (113 Nm) (lug nut). This figure is independently verified against OEM service data.

New to torquing wheels? Read our How lug nut torque works — the complete guide for star-pattern sequence, re-torque intervals, and how to read a lug spec — then use the 2025 Nissan Pathfinder numbers above.
